Scotsman UN324A-1 Undercounter Air Cooled Nugget Ice Machine, 24″ Wide, 340 lb/24 hr, 80 lb Storage, 115/60/1

Introduction

The Scotsman UN324A-1 Undercounter Air Cooled Nugget Ice Machine is made with an R-134A refrigerant that provides a reliable performance. It features a slide back door that offer easy access to the ice in the bin while the included ice scoop provides sanitary serving.The ice machine produces up to 440 lb of ice per 24 hrs and has a storage capacity of 80 lb of ice.

The commercial ice machine has an external air filter that’s simple to clean while the greaseless bearing reduces maintenance. It’s made with a control panelfor a quick and easy operation while the stainless steel evaporator improves durability.

Storage Bin Capacity: 80 lb
Ice Production: 340 lb per 24 hr
Ice Shape: Nugget (3/4″ x 5/16″ x 3/8″)
Measurements: 39″ high x 24″ width x 28.4″ depth
Cooling Type: Air
Heat Rejection:3000 BTU/hr
Ambient Temperature Range: 50-100F
Water Temperature Range: 40-100F
Water Pressure: 20-80 psig
Electrical: 115V/60/1
Refrigerant Type: R-134A
Warranty: 3 Year Parts and Labour, 5 Years on Compressor
Made in USA
